Kubota Z232KW-42 Brand New & Used Lawn Mower

Product Description

Kubota Z232KW-42 — Product Specification

Model & Series

• Series: Z200 (Zero-Turn)

• Model: Z232KW-42

Powertrain & Engine

• Engine Type: Air-cooled, 2-cylinder gasoline engine

• Engine Model: Kawasaki FR651V

• Displacement: 726 cc

• Gross Power: 21.5 HP (at 3,600 rpm)

• Starting System: Key switch / electric start

Transmission

• Type: Hydrostatic transmission (Two-range HST) with gear reduction

• Transaxle: Hydro-Gear ZT-2200 integrated zero-turn transaxles

• Speed:

  • Forward: 0 – 6.5 mph

  • Reverse: 0 – 4 mph

• Parking Brake: Cog-style / hand lever lock

Mower Deck

• Deck Width: 42 in

• Deck Construction: 10-gauge welded steel, 4.5 in deep

• Drive Type: Belt drive

• Lift System: Mechanical, foot-assisted lift and lock

• Cutting Height Range: 1.5 in – 4.25 in, adjustable in ¼-inch increments

• Blades: 2

• Blade Tip Speed: ~17,700 ft/min

• Mounting System: Parallel-linkage

• Anti-Scalp Rollers: Rigid

Frame & Structure

• Operator Protection: Fixed ROPS (Rollover Protection Structure)

• Steering Controls: Dual hydraulic-damped hand levers

• Comfort Features:

  • Sliding high-back seat with armrests

  • Low vibration floor mat

  • Cup holders

  • Sight storage compartment

Dimensions & Weight

• Overall Length: ~1,890 mm

• Overall Width: ~1,400 mm (with deck) / ~1,076 mm (without deck)

• Overall Height (ROPS): ~1,693 mm

• Wheelbase: ~1,236 mm

• Tire Sizes:

  • Front: 11 × 4 – 5

  • Rear: 18 × 7.5 – 10

• Ground Clearance: ~104 mm

• Shipping / Operating Weight: ~292 kg (with mower and fuel)

Capacities

• Fuel Tank: ~13.6 L

• Battery: 12 V, U1 type

• Oil (Engine): ~2.3 qt

• Transaxle / Hydraulic Fluid: ~1.6 – 1.68 qt

Performance

• Drive Speed and Control: Smooth and precise via dual levers

• Maneuverability: Zero-turn radius for tight mowing around obstacles

• Durability: Heavy-duty welded deck for consistent, high-quality cut

Safety & Additional Features

• Seat Safety Switch and Control Lever Safety Switch

• Fixed ROPS for stability on slight gradients

• Mechanical PTO clutch with electric control

• Keyless / safety-aware starting mechanism

• K-Ride Comfort System for reduced vibration during long mowing sessions

Operator Convenience

• Dial-based cutting height adjustment for quick and precise setup

• Deep-seated, cushioned seat with ergonomic armrests

• Ample legroom and a wide foot pan

• Low-noise and low-vibration operation for comfortable mowing
